Description
JMP Flexible Impeller Kit #7400-01K(Also used in Volvo Penta D6 Series Engines, and Yanmar 6LY Series Engines)
Kit Includes:
*Some applications do not require all items in kit
JMP Marine Flexible Impeller #7400-01
QTY:1
Gasket (GAK0016)
QTY:1
Gasket (GAK0062)
QTY:1
O-Ring (ORG0013)
QTY:1
O-Ring (ORG0022)
QTY:1
Replacement For:
– Cummins 650607
– Caterpillar 2637536 or 263-7536
– Detroit Diesel 5193602 / 5196629
– Doosan 65.06084-0003
– Jabsco 920-0001
– Johnson 09-1028B / 09-1028B-1 / 09-1028BT-1
– John Deere RE526661, RE49490
– Kohler 352122
– Northern Lights 25-11011
– Onan 132-0436
– Perkins 0460024 / 24880031 / 24880178
– Sherwood 18200 / 18200K
– Sierra 23-3308 / 23-3309 (JMP Kit does not include screws or rubber seals)
– Volvo Penta 801277 / 825941 / 877061 / 875593 / 3841697 / 20799057 / 21422647 / 21951356
– Yanmar 123325-42020 / 127610-42200 / 120650-42310
JPR-JD25UH (John Deere Replacement Sea/Raw Water Engine Cooling Pump)
For John Deere Engine Models:
4045DFM50, 4045DFM70, 4045TFM50, 4045TFM75, 6068SFM50, 6068TFM50, 6068TFM75, 6068TFM76
Compatible to Genuine: NO
Reason Not Compatible: Changes made to End Cover, O-Ring for Cover, Cover Screw, Cam, Wear Plate, Oil Seal, Mechanical Seal, Shaft
JPR-VP0040DB (Volvo Penta Replacement Sea/Raw Water Engine Cooling Pump)
For Volvo Penta Engine Models:
D4-225A-E, D4-260A-E, D4-260D-E, D4-300A-E, D4-300D-E
Compatible to Genuine: YES
JPR-VP0050D (Volvo Penta Replacement Sea/Raw Water Engine Cooling Pump)
For Volvo Penta D5/D7 Series Engine Models:
D5A-A T/TA, D7A-A T/TA, D7C-A TA, D7A-B TA, D7C-B TA
Compatible to Genuine: YES
JPR-V1000 (Volvo Penta Replacement Sea/Raw Water Engine Cooling Pump)
For Volvo Penta Engine Models:
AD31/41/43, TAMD31/41/42, KAD32/42/44, KAMD42/43/44 (3583115/3581558),
AD31/41, MD31, TMD31/41, TAMD31/41/42, KAD32/42/43/44, KAMD42/43/44 (860629)
Compatible to Genuine: No
Reason Not Compatible: Changes made internally for better quality & performance
JPR-NL20IP (Northern Lights Replacement Gen Set Sea/Raw Water Engine Cooling Pump)
For Northern Lights Engine Models:
L944D, M944W, NL944D2, M30CW, M944T, NL944T, M38CR2
Compatible to Genuine: NO
Reason Not Compatible: Changes made internally for better quality & performance
Used in the following JMP Marine Electro-Magnetic Clutch Pump(s):
JPR-M25IP (Multi-Purpose pump widely used in agricultural, industrial and marine applications)
Used in the following JMP Marine General Multi-Purpose Pump(s):
JPR-25UP (Multi-Purpose pump for such applications as bottling systems, cleaning solutions, sewage treatment & marine uses)
IMPELLER 7400-01 DIMENSIONS & SPECS:
| A (Impeller Dia) | 65mm |
| B (Impeller Width) | 50mm |
| C (Shaft Dia) | 16mm |
| No. of Blade | 8 |
| Insert Type | Spline Drive(12) |
| Impeller Weight (approx) | 0.45 LBS |
WHY USE JMP MARINE FLEXIBLE IMPELLERS vs ALL OTHERS?
JMP Marine (JMP Corp) performs total “IN HOUSE MANUFACTURING” meaning that they do not outsource any part of the process, including materials, as all the other brands today must do. This ensures the highest standards of quality control making sure that their consumers, as yourself, have the utmost confidence and peace of mind that you are receiving a product without comprise. You will get the QUALITY & PERFORMANCE you are looking for and more!
JMP Marine Flexible Impellers DO NOT USE HARMFUL CHEMICALS thereby ensuring the protection of our environment.
JMP has developed a unique formula taken over 40 YEARS OF EXPERIENCE producing an impeller mixture that has been specifically designed for seawater & raw water applications resulting in a much more durable longer lasting product vs the Neoprene and Nitrile of other brands today.
JMP Marine goes a step further . . . in developing an added mixture they call “WAX BRANDING” which is infused throughout the impeller material and has aided in the result of an impeller that can last up to 3 times longer than all others out there.
JMP Marine uses “BRASS INSERTS” vs stainless steel. Even though this does take longer, it produces a machined product that is of better quality resulting in a much MORE DURABLE LONGER LASTING PRODUCT.
